Riegl MiniVUX-1UAV

Type laserscanner: Luftbåren scanner
Rekkevidde: Normal (400-800m)
Bruksområder: Is og snø, Ubemannet fartøy, Overvåkning av bevegeler, Arkeologi og kulturminner, Skogsdrift, Byggeplass, Ressursforvaltning
Laser-klasse: Klasse 1 (Øyesikker)
Produsent:

The new RIEGL miniVUX-1UAV is a user-friendly and cost-efficient device to acquire survey-grade measurement data by use of remotely piloted helicopters and unmanned aircrafts for a variety of applications.

Based on RIEGL's sophisticated waveform processing LiDAR technology, the RIEGL miniVUX-1UAV provides high-speed data acquisition using echo signal digitization and online waveform processing. Its excellent multiple-target capability enables achieving superior measurement results even under adverse atmospheric conditions. The 360° field of view allows data acquisition of the entire surroundings, a well designed housing supports mounting even under limited weight and space conditions.

Main Features

  • Extremely compact, lightweight (1.55 kg), and robust
  • 360° field of view
  • Stable aluminium housing, ready to be mounted to fixed-wing, rotary-wing, and multi-rotor UAVs
  • RIEGL’s unique echo signal digitization and online waveform processing
  • Multiple target capability – up to 5 target echoes per laser shot
  • Scan speed up to 100 scans/sec
  • Measurement rate up to 100,000 measurements/sec
  • Mechanical and electrical interface for IMU mounting
  • Exceptionally well suited for measuring snowy and icy terrain

Main Applications

  • Agriculture & Forestry
  • Archeology and Cultural Heritage Documentation
  • Construction-Site Monitoring
  • Glacier and Snowfield Mapping
  • Landslide Monitoring
